Chapter 13 Specifications

249

Specifications Chapter 13

13.1 Instrument Specifications

Measurement Ranges

Measurement Method

100 M range

high-precision

Measurement range and f.s.

Number of

ranges

OFF

0.000 00 m (10 m range) to 1200.0 M (1000 M range)

10 M or lower range: f.s.=1,000,000dgt.

100 M or greater range: f.s.=10,000dgt.

0.000 00 m (10 m range) to 120.000 0 M (100 M range)

f.s.=1,000,000dgt.

ON −

0.00 m (1000 m range) to 1200.00  (1000  range)

f.s.=100,000dgt.

Measurement signal Constant current

Measurement method Four-terminal

Measurement terminals Banana terminals

SOURCE A Current detection terminal

SOURCE B Current sourcing terminal

SENSE A Voltage detection terminal

SENSE B Voltage detection terminal

GUARD Guard terminal
