Hioki RM3545 User Manual

12.2 Printing
248
 List of measurement conditions and settings
MODEL RM3545-02
NO. 000000000
VER. 1.00
RANGE 10mOhm(1A)
SPEED FAST
AVG 10
OVC ON
DELAY 10ms
A.HOLD OFF
CALIB AUTO
TC OFF
0 ADJ OFF
SCALE OFF
LINE AUTO(60Hz)
TRIG INT
I/O NPN
I/F PRINT
 Statistical calculation results
DATE - TIME 2013-07-31 14:01:11
NUMBER 11
VALID 10
AVERAGE 1200.160mOhm
MAX 1200.200mOhm (No = 9)
MIN 1200.130mOhm (No = 1)
Sn 0.00020mOhm
Sn-1 0.00028mOhm
Cp 0.19
Cpk 0.03
COMP Hi 4
COMP IN 6
COMP Lo 0
BIN0 10.000mOhm - 0.000mOhm 3
BIN1 20.000mOhm - 10.000mOhm 1
BIN2 30.000mOhm - 20.000mOhm 3
BIN3 40.000mOhm - 30.000mOhm 2
BIN4 50.000mOhm - 40.000mOhm 3
BIN5 60.000mOhm - 50.000mOhm 10
BIN6 70.000mOhm - 60.000mOhm 2
BIN7 80.000mOhm - 70.000mOhm 2
BIN8 90.000mOhm - 80.000mOhm 3
BIN9 100.000mOhm - 90.000mOhm 3
Out of BIN 5
The “Valid” statistical calculation result indicates the number (count) of data samples not
subject to errors such as measurement faults.
