10.4 Ext
ernal I/O Sett
ings
214
Switching Ou
tput Mode
s (JUDGE Mod
e/ BCD Mode)
1
Open t
he Se
ttings
Screen.
2
Open t
he EX
T I/O
Setting
Scre
en.
3
Select the output mode.
4
Return to the Measurement screen.
The Settin
gs screen
appears.
Switch the function menu
to P.
2/3.
1
2
Move
the cur
sor to th
e [I/O]
tab with the left and right cur-
sor keys.
2
JUDGE mode (default)
BCD mode
Selection
1
Return
to the
Measurement screen.
221
223
