8.3 Multiplexer Settings
153
8
Setting the connection and measurement method for individual channels
1
Open the Settings Screen.
2
Open the Multiplexer Channel Settings screen.
3
Move to the channel you wish to set.
<Hint>
You can copy the settings for the selected channel to the next channel with the
key. (Only the settings shown on the screen will be copied. However, unit and
pin settings will not be copied.)
You can return to the [MUX2] tab with the key.
The Settings screen
appears.
Switch the function menu
to P.2/3.
1
2
Move the cursor to the
[MUX1] tab with the left and
right cursor keys.
Select the channel to set.
To Next Page
