10.5 Checking External Control
216
4
Perform the EXT I/O test.
5
Return to the EXT/IO setting screen.
6
Return to the Measurement screen.
Output signals
Allows you to perform signal oper-
ations. (ON: Reverse video; OFF:
Normal display)
: Select signal.
: Turn signal ON.
: Turn signal OFF.
Input signals
Displays the signal state. (ON:
Reverse video; OFF: Normal dis-
play)
Return to the
EXT/IO setting screen.
Return to the
Measurement screen.
