11.2 Preparations before Use (Connections and Settings)
229
11
“GP-IB” is only displayed on model RM3545-01 (equipped with GP-IB).
2. Connect the GP-IB cable.
Connect the GP-IB cable to the GP-IB connector. When connecting the cable, be sure to
tighten the connector in place with screws.
4
Select the instrument's address.
5
Select the interface message terminator.
6
Return to the Measurement screen.
Setting range: 0 to 30 (default: 1)
Move the cursor to the setting you
wish to configure. Make the value
editable with the key.
2
Move the cursor to the digit you
wish to set with the left and right
cursor keys. Change the value
with the up and down cursor keys.
Change
values.
1
Move among
digits.
3
Accept
( Cancel)
1
2
LF (default)
CR+LF
Selection
Return to the Measure-
ment screen, and enable
the communications inter-
face.
Rear Panel
Recommended cable:
HIOKI Model 9151-02 GP-IB
Connector Cable (2 m)
To Next Page
