11.4 Auto-Exporting Measured Values (at End of Measurement) (Data Output Function)
235
11
Output data format
Measured value format when scaling is off
(The measured value format varies depending on scaling. (p.77))
Changing the number of digits in the measured value will not change the format. Undis-
played digits have a value of 0.
For positive measured values, a space (ASCII 20H) represents the “+” sign.
When ±OvrRng is displayed, values are ±1E+20.
When a measured value fault occurs, values are ±1E+30.
• This function is not applicable to the GP-IB Interface.
• This function cannot be used when the scan function is set to auto or step while using the
MUX measurement terminals.
• When using the internal trigger [INT], data is automatically sent at TRIG signal input or
when the key is pressed.
• Do not use commands when data output is ON. Doing so may cause measured values to
be sent twice or other issues.
• Resistance value (Absolute value display, unit: )
Low-
power
Measurement
Range
Measured Value ±OvrRng Measurement Fault
OFF 10 m ±
.E-03 ±10.00000E+19 +10.00000E+28
100 m ±.E-03 ±100.0000E+18 +100.0000E+28
1000 m ±
.E-03 ±1000.000E+17 +1000.000E+27
10 ±.E+00 ±10.00000E+19 +10.00000E+29
100 ±
.E+00 ±100.0000E+18 +100.0000E+28
1000 ±.E+00 ±1000.000E+17 +1000.000E+27
10 k ±
.E+03 ±10.00000E+19 +10.00000E+29
100 k ±.E+03 ±100.0000E+18 +100.0000E+28
1000 k ±
.E+03 ±1000.000E+17 +1000.000E+27
10 M ±.E+06 ±10.00000E+19 +10.00000E+29
100 M ±
.E+06 ±100.0000E+18 +100.0000E+28
1000 M ±.E+06 ±1000.000E+17 +1000.000E+28
ON 1000 m ±.E-03 ±1000.00E+17 +1000.00E+27
10 ±.E+00 ±10.0000E+19 +10.0000E+29
100 ±
.E+00 ±100.000E+18 +100.000E+28
1000 ±.E+00 ±1000.00E+17 +1000.00E+27
• Resistance value (Relative value display, unit: %)
Measured Value ±OvrRng Measurement Fault
±
.E+00 ±100.000E+18 +100.000E+28
• Temperature, temperature conversion display (unit: °C)
Measured Value ±OvrRng Measurement Fault
±
.E+00 ±100.0E+18 +100.0E+28
