F: Calculation time (unit: ms)
G: Self-calibration time (unit: ms)
N: Number of average iterations (unit: iterations)
*1 When LP is on, OVC is fixed to on.
*2 When using the SLOW2 measurement speed with low-power resistance measurement on, the
instrument will performing averaging with two iterations internally even if the averaging function
is set to off.
Shortest measurement times when using the internal trigger source with continuous measurement
on (free-run)
LP OFF (unit: ms), tolerance: ±10%±0.2 ms
LP ON (unit: ms), tolerance: ±10%±0.2 ms, Only with OVC on
Shortest conditions
Delay: 0 ms, TC: ON, Comparator: ON, OVC: OFF, Average: OFF,
Self-Calibration: MANUAL, Contact improver: OFF, Scaling: OFF
Measured value display switching: None
* When using the MUX mesurement terminals, the shortest measurement time is 1.7 ms only in
the 10 m range.
Setting Time
Statistical calculation: OFF
Scaling: OFF
Measured value display switching: None
0.3
Self-calibration setting Time
Auto
5.0
Manual
0.0
Trigger source, continuous measurement Number of iterations
When using the internal trigger source with continuous mea-
surement on (free-run)
1
(
Moving Avg.)
When using an external trigger source or with continuous
measurement off (non-free-run)
Varies with setting.
*2
Range
FAST MEDIUM
SLOW1 SLOW2
50 Hz 60 Hz 50 Hz 60 Hz
1000 k or lower range 1.0* 20.7 17.4 101 201
10 M or greater range 20.7 17.4 20.7 17.4 101 201
Range
FAST MEDIUM
SLOW1 SLOW2
50 Hz 60 Hz 50 Hz 60 Hz
1000 m 71 65 111 98 431 631
10 111 105 151 138 471 671
100 111 105 151 138 471 671
1000 113 107 153 140 473 673
