Chapter 13 Specifications
267
13
(22)Temperature Conversion Function (T)
(23)Statistical Calculations
Operation Utilizing the temperature-dependent nature of resistance, the temperature con-
version function converts resistance measurements for display as tempera-
tures.
Formula
T display range -9999.9 to 9999.9°C
Setting ON/ OFF
(Fixed when the comparator function is off; T is automatically turned off when
TC, the statistical calculation function, and the BIN function are on.)
Default setting OFF, t
1
: 23.0°C, R
1
: 1.000 0 , k : 235.0
Δt : Temperature increase (°C)
t
1
: Winding temp. (°C, cool state) when measuring initial resistance R
1
Setting range: -10.0 to 99.9°C
t
2
: Ambient temp. (°C) at final measurement
R
1
: Winding resistance () at temp. t
1
(cool state) Setting range: 0.001  to 9000.000 M *
R
2
: Winding resistance () at final measurement
k : Reciprocal (°C) of temp. coefficient of conductor material at 0°C
Setting range: -999.9 to 999.9
* When set using the instrument’s keys, the input range will reflect the range and scaling coefficient with
a maximum resolution of 1 n and a maximum value of 9 G.
)()(
21
1
2
tktk
R
R
t +−+=Δ
Operation Statistical calculations are performed on measured values.
Setting ON/ OFF (The statistical calculation function is automatically turned off when
T is on while using the MUX measurement terminal setting.)
Maximum number of
data points
30,000
Calculations Total data count, Number of valid data samples, Mean, Minimum value (index
no.), Maximum value (index no.), Standard deviation of sample,
Population standard deviation
• When the comparator function is ON
Count for each comparator judgment, Process capability indices (disper-
sion, bias)
• When the BIN function is ON
Count for each BIN number, OUT (Hi or Lo) count for all BIN numbers,
invalid BIN count
Clearing calculations Clear all data / clear 1 data point (to revert to data immediately before mea-
surement)
Default setting OFF
