Chapter 13 Specifications
278
(4) Measurable range
(5) Contact specifications
2-wire
Measurement current Instrument with Z3003: 1 A DC or less
Externally connected device: 1 A DC or less, 100 mA AC or less
Measurement frequency Externally connected device: DC, 10 Hz to 1 kHz
Contact type Mechanical relay
Maximum allowable
voltage
33 V RMS and 45.7 V peak or 70 V DC
Maximum allowable
power
30 W (DC) (Resistance load)
Contact service life 4-wire: 50 million cycles, 2-wire: 5 million cycles (reference value)
No. Pin name No. Pin name No. Pin name
1 TERM2 18 TERM9 34 TERM17
2 TERM1 19 TERM10 35 TERM18
3 TERM2 20 TERM11 36 TERM19
4 TERM3 21 TERM12 37 TERM20
5 TERM4 22 TERM11 38 TERM19
6 TERM3 23 TERM12 39 TERM20
7 TERM4 24 TERM13 40 TERM21
8 TERM5 25 TERM14 41 TERM22
9 TERM6 26 TERM13 42 TERM21
10 TERM5 27 TERM14 43 GUARD
11 TERM6 28 TERM15 44 GUARD
12 TERM7 29 TERM16 45 EX B (EX Hi)
13 TERM8 30 TERM15 46 EX B (EX Hi)
14 TERM7 31 TERM16 47 EX A (EX Lo)
15 TERM8 32 TERM17 48 EX A (EX Lo)
16 TERM9 33 TERM18 49 EX GUARD
17 TERM10 50 EARTH
