8.7 Command Message Description
199
8
Chapter 8 Controlling the Instrument From a Computer
Total patient leakage
current :
Patient - Earth
––––––
Total patient leakage
current :
SIP/SOP
––––––
Total patient leakage
current :
F-type applied part

Total patient leakage
current :
Metal accessible part

Patient auxiliary
current
––––––
Free current––––––
Measurement modes
Special test condition (Specific applied voltage)
Class-I equipment Class-II equipment
Internally powered
equipment
Application
of 110%
voltage:
Positive
phase
Application
of 110%
voltage:
Negative
phase
Application
of 110%
voltage:
Positive
phase
Application
of 110%
voltage:
Negative
phase
Application
of 110%
voltage:Pos-
itive phase
Application
of 110%
voltage:
Negative
phase
: Can be set, –: Cannot be set
Sets and queries switches(only ST5540)
Syntax
Command
Query
Response
:CONFigure:SWITch <characters>
:CONFigure:SWITch?
<character value 1>,<character value 2>,<character value 3>
<character value 1> = OFF/ON
OFF : S10 : OFF
ON : S10 : ON
<character value 2> = OFF/ON
OFF : S12 : OFF
ON : S12 : ON
<character value 3> = OFF/ON
OFF : S13 : OFF
ON : S13 : ON
Function
Command Sets manual measurement switches.
Query Returns the manual measurement switches setting as alphabetic characters.
Example
Command
:CONFigure:AUTO OFF;:CONFigure:SWITch ON,OFF,OFF
Sets manual measurement switches to S10=ON, S12=OFF, S13=OFF.
Query
Response
:CONFigure:AUTO OFF;:CONFigure:SWITch?
:CONFIGURE:SWITch ON,OFF (Headers : ON)
ON,OFF,OFF (Headers : OFF)
Manual measurement switches has been set to S10=ON, S12=OFF, S13=OFF.
