8.7 Command Message Description
217
8
Chapter 8 Controlling the Instrument From a Computer
Syntax
Response <numerical value 1>,<numerical value 2>,<numerical value 3>,
<numerical value 4>,<numerical value 5>,<numerical value 6>,
<numerical value 7>,<numerical value 8>
<numerical value 1> = Maximum value (NR3)
<numerical value 2> = Judgement (NR1)
0 : Equal to or less than the allowable value (PASS)
1 : Greater than the allowable value (upper limit) (FAIL)
2 : Smaller than the allowable value (lower limit)(LOW)
3 : No judgment
<numerical value 3> = Power supply polarity (NR1)
0 : Positive phase
1 : Negative phase
(When the equipment under test is internally powered equipment, touch cur-
rent (enclosure - line). When enclosure - line leakage current, the value is 0)
<numerical value 4> = Equipment under test status (NR1)
0 : Normal condition
1 : Single-fault condition (Disconnection of one wire in power line)
2 : Single-fault condition (Disconnection of protective earth conductor)
3 : Single-fault condition
(Application of 110% voltage: Positive phase)
4 : Single-fault condition
(Application of 110% voltage: Negative phase)
5 : Single-fault condition (line voltage application: L)
6 : Single-fault condition (line voltage application: N)
<numerical value 5> = Measurement network filter (NR1)
When network A is selected
0 : OFF, 1 : ON
When network B1 or B2 is selected
0 : OFF, 1 : ON
When network C is selected
0 : OFF, 2 : ON1(U2), 3 : ON2(U3), 4 : ON1(U1), 5 : ON2(U1)
When network D, E, F or G is selected
0: OFF
Reads saved data
