8.7 Command Message Description
219
8
Chapter 8 Controlling the Instrument From a Computer
Error
I
f the set data unit number is higher than the total number of data units, an exe-
cution error occurs.
Reads saved data
Maxi-
mum
value
Judge
ment
Power
supply
polarity
Equipment under
test status
Filter
Target
current
Application
of 110% of
rated
voltage
under
other
conditions
Specific
110%
voltage
applica-
tion
Switch
2.345
mA
PASS Positive
phase
Normal condition ON AC+DC None None All Off
2.362
mA
PASS Negative
phase
Normal condition ON AC+DC None None All Off
2.510
mA
PASS Positive
phase
Single-fault condition
(
Disconnection of protective earth
conductor
)
ON AC+DC None None All Off
2.610
mA
FAIL Negative
phase
Single-fault condition
(
Disconnection of protective earth
conductor
)
ON AC+DC None None All Off
2.456
mA
PASS Positive
phase
Single-fault condition
(Disconnection of one wire in
power line)
ON AC+DC None None All Off
Saves automatic measurement results
Syntax
Command
:MEMory:SAVE:AUTO
Function
Command Saves automatic measurement results(date, Equipment name, Control number,
Grounding class, Applied part, network, measurement mode, Maximum value,
test condition setting at maximum value acquisition, judgement result)in mem-
ory.
*
When network B1 or B2 is selected
Example
Command
:MEMory:SAVE:AUTO
Saves automatic measurement results.
Error
An execution error occurs in the following cases:
• When the measurement mode is not selected
• When a mode other than "leakage current mode" is set
• In automatic measurement
• When there is not enough memory space
• When there is not enough memory space
• When the equipment name and control number are the same as those of
saved data, but the network, grounding class, and applied part differ
• When there is no data
• In manual measurement
Note
• Use this command after executing the :MODE command to activate the mea-
surement mode.
• After automatic measurement, save data before starting the next automatic
measurement.
