8.7 Command Message Description
221
8
Chapter 8 Controlling the Instrument From a Computer
Sets and queries the measurement mode
Syntax
Command
Query
Response
:MODE <characters>
:MODE?
<characters>
<characters>=OFF/EARTh/ENCLosure1(ENCL1)/ENCLosure2(ENCL2)/
ENCLosure3(ENCL3)/PATient1(PAT1)/PATient2(PAT2)/PATient3(PAT3)/PAUX-
iliary/TOUCh1(TOUC1)/TOUCh2(TOUC2)/TOUCh3(TOUC3)/
PATientP2E(PATP2E)/PATientSIPSOP(PATSIPSOP)/PATientFTYPE(PAT-
FTYPE)/PATientMP(PATMP)/TPATientP2E(TPATP2E)/TPATientSIPSOP(TPAT-
SIPSOP)/TPATientFTYPE(TPATFTYPE)/TPATientMP(TPATMP)/FREE
When network A, D, E, or F is selected
OFF : Mode not selected
(Initial screen : command)
(Initial screen, system screen : query)
EARTh : Earth leakage current
ENCLosure1 : Enclosure - Earth leakage current
ENCLosure2 : Enclosure - Enclosure current
ENCLosure3 : Enclosure - Line leakage current
FREE : Free current (only network A)
When network B1 is selected
OFF : Mode not selected
(Initial screen : command)
(Initial screen, system screen : query)
ENCLosure1 : Enclosure - Earth leakage current
ENCLosure2 : Enclosure - Enclosure current
PATient1 : Patient leakage current I
PATient2 : Patient leakage current II
PATient3 : Patient leakage current III
PAUXiliary : Patient auxiliary current
FREE : Free current
When network C or G is selected
OFF : Mode not selected
(Initial screen: command)
(Initial screen, system screen : query)
EARTh : Earth leakage current
TOUCh1 : Touch current Enclosure - Earth
TOUCh2 : Touch current Enclosure - Enclosure
TOUCh3 : Touch current Enclosure - Line
