8.7 Command Message Description
222
When network B2 is selected
OFF : Mode not selected
(Initial screen : command)
(Initial screen, system screen: query)
EARTh : Earth leakage current
TOUCh1 : Touch current Enclosure - Earth
TOUCh2 : Touch current Enclosure - Enclosure
PAUXiliary : Patient auxiliary current
PATientP2E : Patient auxiliary current Patient - Earth
PATientSIPSOP : Patient leakage current SIP/SOP
PATientFTYPE : Patient leakage current F-type applied part
PATientMP : Patient leakage current Metal accessible part
TPATientP2E : Total patient leakage current
Applied part- Earth
TPATientSIPSOP : Total patient leakage current SIP/SOP
TPATientFTYPE : Total patient leakage current F-type applied part
TPATientMP : Total patient leakage current Metal accessible part
FREE : Free current
Function
Command Sets the measurement mode and changes the screen.
Query Returns the measurement mode setting as alphabetic characters.
Example
Command
:MODE EARTH
Sets Earth leakage current measurement mode.
Query
Response
:MODE?
:MODE EARTH (Headers : ON)
EARTH (Headers : OFF)
Earth leakage current measurement mode has been set.
Sets and queries the measurement mode
