3.5 Pre-Test Inspection
45
3
Chapter 3 Setting Preparations
(1) If the voltage check results in NG
(2) If the current check results in NG
(3) If the VA check results in NG
Check examples
• Check the voltage of the power supply.
• Check whether the circuit breaker is ON.
• The internal fuse (power) may be blown.
Check connections.
The maximum allowed power supply voltage is 275 V.
Reduce the current to 20 A or less.
The VA (voltage x current) must be 5,000 VA or lower.
To Next Page
