Hitachi IJ UX Service Manual

2-52
(2) Automatic ink replenishment data (AUTOSPLY.TXT)
[Example]
- Control sequence
Norm. : Normal ink concentration
Low : Performing the reducing concentration control due to the high ink concentration
High : Performing the increasing concentration control due to the low ink concentration
- Initial level (High-speed machine)
The position of initial level at the high-speed machine (1 to 3) (0: At the other model)
- Mode
Result of Automatic ink replenishment (Refer to the next page (3).)
- Ambient temperature
Ambient temperature measured by the sensor in the neck of Printhead
- Viscometer temperature
Ink temperature measured by the sensor in the viscometer
- Dot count
The number of printed ink dots during the each ink replenishment interval
- Ink replenishment (for dot count)
Ink replenishment for printed ink dots (Replenishment time; Hour:Minute:Second)
- Makeup replenishment (to an initial level)
Makeup replenishment to the initial level (Replenishment time; Hour:Minute:Second)
- Ink replenishment (to an initial level)
Ink replenishment to the initial level (Replenishment time; Hour:Minute:Second)
- Finish time
Finished time of replenishment (Hour:Minute:Second)
<Process of ink replenishment control>
Ink
Concent-
ration
Sequence Initial level sensor: OFF Initial level sensor: ON
Normal Normal ink
concentration
(1) Ink replenishment (for dot count (*1))
(2) Makeup replenishment
(to the initial level)
(1) Ink replenishment
(for dot count(*1))
(No makeup replenishment)
Low
Increasing
concentration
control
(1) Ink replenishment (for dot count (*1))
(2) Ink replenishment (to the initial level)
(No makeup replenishment)
No replenishment
High Reducing
concentration
control
(1) Ink replenishment (*2)
(2) Makeup replenishment
(to the initial level)
No replenishment
(*1) In case of “Dot count < 65,536 dot”, ink replenishment is not performed and the dot count value
is added to next count.
(*2) Ink replenishment amount is the equivalent amount of Dot count – 3.2ml. In case of minus value,
ink replenishment is not performed.
№ Date Start time
Control
sequence
Initial level
(High-
speed
machine)
Mode
Ambient
temperature
Viscometer
temperature
Ink
Pressure
Cumulative
print count
Dot count
Ink
r e p l e n i s h m e n t
(for dot
count)
Makeup ink
replenishment
(to an initial
level)
Ink
replenishment
(to an initial
level)
Finish time
1 2011/7/7 0:02:49 High 1 2 26
23 0.297 0 0 0:00:00 0:00:00 0:00:00 0:02:49
2 2011/7/7 0:03:59 Norm. 1 3 26 23 0.257 0 0 0:00:00 0:00:00 0:00:00 0:03:59
3 2011/7/7 0:04:36 Norm. - B 26 23 0.256 17 1292 0:00:00 0:00:00 0:00:00 0:04:36
4 2011/7/7 0:07:43 Norm. - 2 26 23 0.299 24 214 0:00:00 0:00:00 0:00:00 0:07:43
5 2011/7/7 0:11:11 Low 1 3 26 23 0.298 43 7572 0:00:00 0:00:00 0:00:00 0:11:11
6 2011/7/7 0:22:33 Norm. - B
26 23 0.256 58 10212 0:00:00 0:00:00 0:00:00 0:22:33
7 2011/7/7 0:30:55 Norm. - 2 26 23 0.299 60 0 0:00:00 0:00:00 0:00:00 0:30:55
8 2011/7/7 0:31:22 Norm. - G 26 25 0.249 65 5655 0:00:00 TimeOver 0:00:00 0:31:52
