3-42
[Signal name and remarks of terminal block (TB3)]
Pin
No.
Name of signal
Input / Output
Remarks
NPN/PNP Interface
NPN/PNP
1
Signal ground
－
2
Signal notifying Completion of signal input
Output
-NPN / PNP can be selected by SW7
3
Signal during calendar Updating
Output
4
Strobe signal
Input
- NPN / PNP can be selected by SW8
5
Signal ground
－
6
Data message number signal bit 11
Input
- NPN / PNP can be selected by SW8
7
Data message number signal bit 10
Input
8
Data message number signal bit 9
Input
9
Data message number signal bit 8
Input
10
Data message number signal bit 7
Input
11
Data message number signal bit 6
Input
12
Data message number signal bit 5
Input
13
Data message number signal bit 4
Input
14
Data message number signal bit 3
Input
15
Data message number signal bit 2
Input
16
Data message number signal bit 1
Input
17
Data message number signal bit 0
Input
18
Calendar stop / Reserve of input
Input
- Signal can be selected by
EZJ130-SW1
- NPN / PNP can be selected by SW8
19
Reserve of signal ground
－
20
Reserved input
Input
21
Reserved input
Input
22
Reserved input
Input
23
Reserved input
Input
24
Reserved power source / External power
supply (Not required when supplying
power from the IJ printer)
Input
- Input can be selected by SW4,SW6
- DC24V, Max.40mA
25
Signal ground
－
26
Reserved
－
27
Power supply for Vision Sensor
Output
- Wrong wiring will cause the board breakdown. Before wiring, be sure to confirm the
terminal signal.
- Be sure to turn OFF the main power, switch before you start the external wiring.
！
Caution wiring for external
