Hitachi UX Twin Nozzle Service Manual

3-43
[ Setting of SW ]
●Setting of SW
[SW4]
SW4
Description
Factory default
setting
Bit 1
Reserved ( Set to OFF )
OFF
Bit 2
Sets host communication (Set to OFF)
OFF
Bit 3
Sets host communication (Set to OFF)
OFF
Bit 4
Switches the filter constant of strobe signal (capacitance)
ON : 0.047 (μF) + 2.2(μF)
OFF : 0.047 (μF)
OFF
Bit 5
Sets the polarity of strobe signal transmitted from host.
Setting
Photocoupler operation
(Voltage level at TB3, pin 8)
ON
OFF
ON
Bit 6
Reserved ( Set to OFF )
OFF
Bit 7
Power supply for Print target detector / Vision Sensor
( OFF: In case of using external power supply )
ON
Bit 8
Sets Power supply
ON: In case of using Power supply
OFF: In case of not using Power supply
ON
[SW5]
SW5
Description
Factory default
setting
Bit 1
Reserved ( Default setting is show in the table on the right.)
OFF
Bit 2
OFF
Bit 3
OFF
Bit 4
ON
Bit 5
OFF
Bit 6
ON
Bit 7
OFF
Bit 8
ON
OFF
ON
ON
4
3
2
1
8
7
6
5
OFF
ON
ON
4
3
2
1
8
7
6
5
