5-24
Back face: Recovery tube,
APH board power supply w
ires, FG wires
,
APH signal wires
,
Video signal wires
,
Heater feeder wires
,
EZJ
135
board signal wires
,
High voltage feed wires
１１
Attach the heater
, the deflection
bas
e, the heater spacer packing and the deflecti
on
base packing.
Deflection base
Heater
Heater
spacer packing
Deflection base packing
APH board pow
er wire
Heater
Harness with terminal
Recover
tube
APH signal wire
High-voltage w
ire
High-voltage w
ire
APH signal wire
Recover
tube
Heater
Harness with terminal
APH board pow
er wire
FG wire
Video wire
Video wire
CN1
connector (2)
CN4
connector (2)
CN3
connector (22)
CN2
connector
(No mark
is indicated)
239
