１２ Place the APH tube assembly on the head base and connect with the recovery tubes.
１３ Fasten the FG and one side of the deflection electrode GD wires together. Screw another side of
the deflection electrode GD wires on the front edge of the head base.
１４ Screw the video signal wires and the high voltage feed wires respectively.
After screwing the high voltage feed wires, coat them with silicone rubber. With respect to the
coating method, refer to the item 5.11 “Deflection base replacement Procedure”, Step ８ .
１５ Assemble the connectors and close the head base rear cover.
１６ Attach the gutter bases, the shutoff valves and the nozzles.
１７ Attach the cable seal plate, the deflection electrodes and the video signal wires.
[Caution] Be careful not to crush/pinch the tubes.
１８ Connect the nozzle excitation connectors and attach all the covers being careful not to pinch the wires.
