Hitachi UX Twin Nozzle Service Manual

2-17
Container
type
Level sensor
Undetected
Detected
Main
ink tank
Too high [OF]
The sensor is not detecting
“overflow” level.
The sensor detected “overflow”
level. (Abnormal)
Initial level [1] /
Sensor [1]
The sensor is not detecting the
level.
The sensor detected the level.
Sensor [2]
The sensor is not detecting the
level.
The sensor detected the level.
Sensor [3]
The sensor is not detecting the
level.
The sensor detected the level.
Ink
reservoir
Sensor [1]
The sensor is not detecting the
level.
Ink is present.
(Cartridge replacement can NOT be made)
Sensor [2]
The sensor is not detecting the
level.
Ink is present.
(Cartridge replacement can NOT be made)
Sensor [3]
“Ink Low Warning” appears.
Ink is present.
(Cartridge replacement can be made)
Makeup
reservoir
Sensor [WHITE]
(Float : UPPER)
The sensor is not detecting the
level.
Makeup is present.
(Cartridge replacement can NOT be made)
The float is located at upper side
and “Sensor [WHITE]” is ON.
Sensor [RED]
(Float : LOWER)
“Makeup Low Warning”
appears.
The float is located at lower side
and “Sensor [RED]” is ON.
Makeup is present.
(Cartridge replacement can be made)
