2-32
Arabic number “2” print CG example (characters size in figure is “12 x 16”)
< Method 1 > < Method 2 >
●You can enhance printing quality by increasing the “character height” setting value and
decreasing distance between printing head and print object, rather than decreasing the
“character height” setting value and increasing distance between printing head and print
object.
Setting the minimum value of “character height” prevents deterioration of printing quality.
●Add items online mode
(1) Function Summary
In the second page of “User Environment Setup” screen, which is the specific screen of
“Service Personnel Maintenance Mode”, the new item of “Add items in online mode” is created.
There will be selections of “Disable”, “24 items” and “100 items”. When the number of print items
currently set is short, the print items will be automatically added.
(2) Add-Items Process
The print items will be added, “Column” by “Column”, using the format of the last column, such
as the number of lines and the character size. If there be created the extra “Column(s)” and the
print item(s) can’t be added in units of “Column”, the print item of the single line, 5x8 (5x7)
character size will be added. Please see below the examples when the print items are added
automatically.
[Example 1]
The print items are added in units of “Column” up to the numbers specified. (24 items are set.)
Before Change After Change
3Lines/1Column (3 items) 3Lines/8Columns (24 items)
No.
Timing when the print items are added automatically.
1
When the transition from off-line to on-line is made manually.
2
When the transition from off-line to on-line is made by external communication.
3
When the registered print data is recalled by external communication or by external
signal.
5x5
5x8
7x10
Column1
5x5
5x8
7x10
5x5
5x8
7x10
…
…
…
Column1
Column8
