E1 Series Servo Drive User Manual Parameters
15-42 HIWIN MIKROSYSTEM CORP.
MD09UE01-1910
Pt No.
Pt519
Size 2
Setting
Range
0000~1111 Default 0000
Name
Output signal
inverse setting 1
Unit
-
Applicable
Motor
All
Effective
After power on
Category
Setup
Reference
-
Description
t.X
O1 signal inversion
0 The signal is not inverted.
1 The signal is inverted.
t.X
O2 signal inversion
0 The signal is not inverted.
1 The signal is inverted.
t.X
O3 signal inversion
0 The signal is not inverted.
1 The signal is inverted.
t.X
O4 signal inversion
0 The signal is not inverted.
1
The signal is inverted.
Pt No.
Pt51A
Size 2
Setting
Range
0000~0001 Default 0000
Name
Output signal
inverse setting 2
Unit -
Applicable
Motor
All
Effective
After power on
Category
Setup
Reference
-
Description
t.X
O5 signal inversion
0 The signal is not inverted.
1 The signal is inverted.
t.

X

Reserved (Do not modify.)
t.X Reserved (Do not modify.)
t.X Reserved (Do not modify.)
