MAINTENANCE
ThinPrep 2000 Processor Operator’s Manual 7.11
7
Figure 7-7
5. Detach tubing from points A and B shown in Figure 7-8.
Figure 7-8
6. Holding the tubing on each side of the valve, slide it out of the valve in the direction shown in
Figure 7-9. Discard tubing.
VP
B
A
Tubing
P
V
P
V
A
B
