7
MAINTENANCE
7.12 ThinPrep 2000 Processor Operator’s Manual
Figure 7-9
7. Locate the replacement tubing. Slide the tubing into the valve using a back and forth motion
while pushing the tubing into the valve. See Figure 7-10. Make sure tubing is fully inserted and
not twisted.
Figure 7-10
8. Connect the replacement tubing to points A and B shown in Figure 7-11. Make sure tubing fully
covers each fitting.
P
V
P
V
