Honda CBF600SA - Page 564

LIGHTS/METERS/SWITCHES
20-16
Remove the wire band.
Remove the handlebar (page 13-8).
Remove the stem nut.
Loosen the pinch bolt.
Remove the top bridge and combination meter
assembly.
DISASSEMBLY
Remove the mounting bolts and the top bridge from
the combination meter.
Remove the screws and lower cover.
WIRE BAND
COMBINATION METER
PINCH BOLTS
STEM NUT
TOP BRIDGE
BOLTS
LOWER COVER
SCREWS
