Level 3 ID
Nr
L3 main menu
categories
L3 main menu
as displayed on
LCD
L3 submenu as
displayed on
LCD
Item code Description
L3.7.1 CALIB PRES Select CALIB PRESS/CALIB TEMP and press OK.
Use the keypad and enter the value of
pressure/temperature that EC350 must
measure. After you enter the value, press OK. The
EC350 calculates the % ERROR. %ERROR is the
difference between the pressure/temperature
value measured by EC350 and the value (the
entered value) that EC350 must measure. The
calibration allows you to make changes to the
instrument to bring the % ERROR to zero.
L3.7.2 CALIB TEMP
L3.8 MTR PROVER Allows you to check the accuracy of the actual
volume of gas flowing through a gas meter.
Press OK. The following items appear.
UC IDIAL RATE
TC IDIAL RATE
I FLOW RT
UC IDIAL RATE, stands for Uncorrected Input
Dial Rate, TC IDIAL RATE stands for Temperature
Corrected Input Dial Rate, and I FLOW RT stands
for Input Flow Rate.
L3.9 DIAGNOSTIC Functions as a sensor, and ensures that the
pulse inputs provided to EC350 are functioning.
L3.9.1 SENSOR TST
L3.10 VIEW LOGS Allows you to view a specified Log Record’s Date,
Time, and CRC value (in decimal).
Actual Log Item Values are not available. This
function is mainly to serve the needs of
Compliance verification. Specify a Log Record
number to begin and then press the Enter Key to
view the actual record’s parameters (Date, Time,
and CRC).
L3.10.1 AT-LOG1
L3.10.2 AT-LOG2
L3.10.3 AT-LOG3
L3.10.4 AT-LOG4
L3.10.5 AT-LOG5
