20 IFP-75/IFP-75HV Installation/Operation Manual — P/N LS10147-001SK-E:D 06/25/2021
Prerequisites for Installation Calculating Current Draw and Standby Battery
Addressable SLC Modules
IDP-MONITOR Standby/Alarm .375 mA mA mA
IDP-MINIMON mA mA
IDP-PULL-SA /IDP-PULL-DA
IDP-MONITOR-2 Standby/Alarm: .75mA mA mA
IDP-MONITOR-10 Standby/Alarm: 3.5mA mA mA
IDP-CONTROL SLC Standby: .375mA
Alarm: .375mA
mA
mA
Aux Pwr Standby: 1.7mA mA
Alarm: 7mA mA
IDP-CONTROL-6 SLC Standby: 2.25mA
Alarm: 2.25mA
mA
mA
Aux Pwr Standby: 8mA mA
Alarm: 20mA mA
IDP-RELAY Standby/Alarm: .255mA mA mA
IDP-RELAY-6 Standby/Alarm: 1.45mA mA mA
IDP-RELAYMON-2 Standby: 1.3mA mA
Alarm: 24mA mA
IDP-ZONE Aux Pwr Standby: 12mA mA mA
Alarm: 90mA mA mA
SLC Standby/Alarm: .27mA mA mA
IDP-ZONE-6 Aux Pwr Standby: 50mA mA mA
Alarm: 270mA mA mA
SLC Standby/Alarm: 2mA mA mA
SLC Accessories
B200SR-WH / IV Intelligent sounder base Aux Pwr Standby: .5mA mA
Alarm: 35mA mA
SLC Standby .3mA mA
B200S-WH / IV Intelligent sounder base Aux Pwr Standby: .5mA mA
Alarm: (high vol) 35mA mA
SLC Standby .3mA mA
B200SR-LF-WH / IV Low Frequency sounder base Aux Pwr Standby: 1mA mA
Alarm: 125mA mA
B200S-LF-WH / IV Low Frequency sounder base Aux Pwr Standby .55mA mA
Alarm (high vol) 140mA mA
SLC Standby .30mA mA
B224RB-WH / IV Relay Base Standby/Alarm: .5mA mA mA
RTS151/151 KEY Alarm: 7.5mA
mA
RA100Z Alarm: 10mA
mA
SLC Isolator Devices
IDP-ISO (Isolator Module) (100 max.) Standby/Alarm: .45mA mA mA
B224BI / IV Isolator Base (50 max.) Standby/Alarm: .5mA
Color Guide: -IV = Ivory color, -BL = Black, -WH = White, -WHITE-White
Accessories Modules
RA-2000 Remote LCD Annunciator (8 max.) Standby: 25 mA mA
Alarm: 50 mA mA
RA-100 Remote LCD Annunciator Standby: 20 mA mA
Alarm: 25 mA mA
RA-1000 Remote LCD Annunciator Standby: 20 mA mA
Alarm: 25 mA mA
5824 Serial / Parallel Module (4 max.) Standby/Alarm: 45mA mA mA
RPS-1000 Power Supply (8 max.) Standby/Alarm: 10 mA mA mA
5496 NAC Expander (8 max.) Standby/Alarm: 10 mA mA mA
5865-4 LED Annunciator
(with reset and silence switches)
(8 max.) Standby: 35 mA mA
Alarm: 145 mA mA
5865-3 LED Annunciator Standby: 35 mA mA
Alarm: 145 mA mA
D e v i c e
# of
Devices
Current per Device
Standby
Current
Alarm
Current
Table 3.3 Current Calculation Worksheet for IDP Devices (Continued)
