Honeywell Thor VM3 User Manual

102 Thor VM3 with Microsoft Windows Embedded Compact 7 User Guide
VMXD Enhanced Dock with Thor VX8/Thor VX9 Power Cable
Determine the type of power supply used with the previous Thor VX8 or Thor VX9 instal-
lation:
• DC/DC Power Supply with Screws on Top of Lid
• DC/DC Power Supply with Screws on Side of Lid
Caution: This dock is recommended for use when replacing an existing
Thor VX8 or Thor VX9 where screen blanking is used. This dock
eliminates the need for wiring changes by enabling the existing
VX8/VX9 power cable and screen blanking box to be used when
the VX8/VX9 is replaced by a Thor VM3 computer. These
instructions are for this dock model only! The Ignition Control
feature is not available when this dock is used.
Warning: The external DC/DC converter previously used with the Thor
VX8 or Thor VX9 must be left in place to provide ground
isolation. Connecting the dock power input directly to vehicle
power could result in a safety hazard or equipment damage.
Warning: The cable shielding must be connected to chassis ground.
Consult the instructions later in this section for the respective
power supply type.
Caution: COM1 is used for screen blanking (via the power cable
connector) and is unavailable when the screen blanking box is
attached. When a screen blanking box is attached, any external
serial device such as a scanner, must be connected to the
COM2 port on the dock. If a screen blanking box is not
connected via the power cable, the COM1 port on the dock is
available for a serial device connection.
These instructions for use with VMXD Enhanced Dock only.

Honeywell Thor VM3 Specifications

General

Stepping	D0
Tjunction	-40 °C
FSB Parity	No
Processor code	SR1X8
Processor cache	1 MB
Processor cores	2
Processor model	E3826
System bus rate	- GT/s
Processor family	Intel Atom®
Processor codename	Bay Trail
Processor frequency	1.46 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor package size	25 x 27 mm
Conflict-Free processor	Yes
Processor front side bus	- MHz
Processor operating modes	32-bit, 64-bit
Graphics & IMC lithography	22 nm
PCI Express configurations	1x1, 1x4, 2x1
Thermal Design Power (TDP)	7 W
Internal memory	4 GB
Internal memory type	DDR3-SDRAM
Storage media	Flash
Compatible memory cards	-
Internal storage capacity	64 GB
Display diagonal	12.1 \
Display brightness	900 cd/m²
Display resolution	1024 x 768 pixels
Graphics card	HD Graphics
Rear camera resolution (numeric)	- MP
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.0+EDR
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
HDMI ports quantity	0
USB 2.0 ports quantity	1
I/O ports	1x CAN-bus, RF
Processor ARK ID	78477
Processor socket	BGA 1170
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Platform	Windows
Bundled software	Data Collection Engine, Microsoft Internet Explorer, Microsoft on-screen keyboard, Configuration Cloning Utility, Screen Blanking, Zoom Zone, Launcher
Operating system installed	Windows 7
AC adapter input voltage	90 - 240 V
Battery capacity	- mAh
Battery life (max)	0.5 h
Certification	EN 55024:2010, MIL-STD-810F, SAE-J1455, CCX
Device type	Tablet PC
Form factor	Slate
Product color	Grey, Silver
Protection features	Shock resistant, Vibration proof, Water resistant
International Protection (IP) code	IP66
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	62 mm
Width	318 mm
Height	260 mm
Weight	3000 g
