Output Calibration
Step Description Press Action
or
until the desired zero value is reached in the upper display.
Upper Display =
(the desired zero calibration value)
Lower Display = ZERO VAL
6 DO MAN
Set 100 % value
Function
FunctionFunction
The controller will store the 0 % value and you will see:
Upper Display =
(the existing span calibration value in counts))
Lower Display = SPAN VAL
or
until the desired span value is reached in the upper
display.
Upper Display =
(the desired span calibration value)
Lower Display = SPAN VAL
For manual calibration, the motor does not move from its
position prior to the start of Position Proportional
calibration.
7
Exit the Calibration Mode
Function
FunctionFunction
The controller will store the 100 % value.
Lower
Display
Lower
Display
Lower
Display
or
SetupSetup
To exit the calibration mode
150 UDC3200 Universal Digital Controller Product Manual 12/04
