Configuration
Function Prompt Selections or
Parameter
Lower Display
Range of Setting
Upper Display
Definition
TO Aout
AUTOMATIC OUTPUT—Contact closure sends
output to the value set at Control prompt AUTO OUT
when the controller is in the Automatic mode.
Reopening the contact returns the controller to the
normal output.
ATTENTION Does not apply to Three Position
Step Control.
TIMER
TIMER—Contact closure starts timer, if enabled.
Reopening the switch has no effect.
AM STA
TO AUTO/MANUAL STATION—Contact closure
causes the control loop to perform as follows:
PV = Input 2
Action = Direct
Control algorithm = PD+MR
PID SET = 2
SP = LSP 2
TO TUNE
INITIATE LIMIT CYCLE TUNING—Contact closure
starts the tuning process. The lower display shows
TUNE ON. Opening the contact has no effect.
SP Init
SETPOINT INITIALIZATION—Contact closure
forces the setpoint to the current PV value. Opening
the contact has no effect.
TRACK
OUTPUT TRACKS INPUT 2—Contact closure
allows Output to track Input 2. While the switch is
open, the output is in accordance with its pre-
defined functionality. When the switch is closed, the
output value (in percent) will track the Input 2
percent of range value. When the switch is
reopened, the output will start at this last output
value and normal PID action will then take over
control. The transfer is bumpless.
TO RSP
TO REMOTE SETPOINT—Contact closure selects
the Remote setpoint.
RST FB
EXTERNAL RESET FEEDBACK—Contact closure
allows Input 2 to override the internal reset value.
To PURGE
TO PURGE—Contact closure forces the loop to
Manual mode with the output set to the Output High
Limit configuration. MAN lights and the Output value
is shown on the lower display. Opening the switch
has no effect.
ATTENTION Does not apply to Three Position
Step Control.
82 UDC3200 Universal Digital Controller Product Manual 12/04
