HP PROCURVE 2910AL User Manual

Configuring Secure Socket Layer (SSL)
Configuring the Switch for SSL Operation
For example, to generate a new host certificate via the web browsers inter-
face:
Certificate Type Box
Key Size Selection
Certificate Arguments
Figure 8-5. Self-Signed Certificate generation via SSL Web Browser Interface Screen
To view the current host certificate in the web browser interface:
1. Proceed to the Security tab
2. Then the
[SSL] button
8-14

HP PROCURVE 2910AL Specifications

General

Model	HP ProCurve 2910al
Switching Capacity	128 Gbps
Throughput	95.2 Mpps
Management	Web, CLI, SNMP
Jumbo Frame Support	Yes
Manageable	Yes
Power	100-240 VAC
Power Supply	Internal
Operating Temperature	0°C to 45°C (32°F to 113°F)
Stacking	Yes
MAC Address Table Size	32000 entries
Routing Protocol	RIP, OSPF
Features	IPv6, VLAN, QoS, ACLs
Operating Humidity	15% to 95% non-condensing
Uplink Ports	4
Power over Ethernet	Yes (PoE+ models available)
