HPE ProLiant Gen9

HPE iLO messages, traps, and errors
iLO POST LED indicators
During the initial boot of , the POST LED indicators flash to display the progress through the boot process.
After the boot process is complete, the HB LED flashes in one second intervals. LED indicators (1 through 6)
illuminate after the system has booted to indicate a hardware failure. If a hardware failure is detected, reset .
For the location of the LED indicators, see the server documentation.
A runtime failure of is indicated by HB constantly remaining in either the On or Off state. A runtime failure of
can also be indicated by a repeated flashing pattern on all eight LEDs. If a runtime error occurs, reset .
The LED indicators have the following assignments.
LED indicator POST code (activity
completed)
Description Failure indicated
None 00 Set up chip selects —
2 02 - Normal operation Scrub done —
HB and 2 82 Kernel launch Subsystem startup failed
if this status remains for
extended period of time
(~60 seconds)
5,4,3,2,1 and blinking 0F Main error - recovery The main payload is
corrupt; the kernel is
running flash recovery.
HB, 7, and 6 steady
5,4,3,2,1 blinking
E0 Kernel error Failure to find and load a
kernel
HB — Flashes as the processor
executes firmware code.
It does not change the
value of the lower seven
LEDs.
—
Event log entries
Event log display Event log explanation
Access options IPMI/DCMI modified by: [user name] The options to access iLO via IPMI/DCMI were
modified by the listed user.
Active Health System cleared by: [user name] The Active Health System was cleared by the listed
user.
Active Health System disabled by: [user name] The Active Health System was disabled by the listed
user.
Active Health System enabled by: [user name] The Active Health System was enabled by the listed
user.
Active Health System logging hardware disabled The Active Health System was disabled in hardware.
Table Continued
302 HPE iLO messages, traps, and errors
