Hypertherm Powermax30 AIR Service Manual

Powermax30 AIR Service Manual 808850 123
6 – Power Supply Component Replacement
9. Peel both thermal protection strips off the heatsink. If the ends of the strips are tucked down between the
heatsink and center panel, firmly grip both corners of the strip and pull up to remove it from the power supply.
Figure 44
10
10

Hypertherm Powermax30 AIR Specifications

General

Built-in Air Compressor	Yes
Output Voltage	83 VDC
Input Voltage	120-240 V
Current Output	15–30 A
Cutting Thickness	Up to 10 mm (3/8 in) recommended cut
Gas Supply	Built-in air compressor
Operating Temperature	-10°C to +40°C (+14°F to +104°F)
