138 Powermax30 AIR Service Manual 808850
6 – Power Supply Component Replacement
8. Complete the following procedures:
a. See Install the component barrier on page 101.
b. See Install the power supply cover on page 99.
c. Reconnect the power cord, and set the power switch to ON (I).
Figure 56
1
2
3
4
