Service Parts
2
22 810440 Service Parts and Procedures Powermax65/85 SYNC
For replacement procedures, refer to the following:
 Replace the air filter assembly on page 83
 Replace the solenoid valve on page 88
 Replace the 90° gas tube fitting on page 92
 Replace the gas tubes on page 91
2
528053 Kit: Solenoid valve (includes gas tubes and screws)
429061 Solenoid valve
101508 Bracket
104488 Tubing: 5/16 inch outer diameter X 7.75 inches
104632 Tubing: 5/16 inch outer diameter X 12 inches
104990 Tubing: 8 mm outer diameter X 1.75 inches
075711 Screw: M4 X 12, pan head
3
528017 Kit: 90° gas tube fitting
015921 90° gas tube fitting
4
528065 Kit: Powermax65/85/105 SYNC Gas tubes
104487 Tubing: 8 mm outer diameter X 3.3 inches (optional – not shown)
104488 Tubing: 5/16 inch outer diameter X 7.75 inches
104632 Tubing: 5/16 inch outer diameter X 12 inches
104990 Tubing: 8 mm outer diameter X 1.75 inches
Item
Part
number
Description and kit contents
