Hypertherm Powermax65 SYNC User Manual

Service Procedures for the Magnetics
6
134 810440 Service Parts and Procedures Powermax65/85 SYNC
Replace the PFC inductor
For kit contents, refer to Power supply interior, magnetics on page 33.
Remove the PFC inductor
1. Set the plasma power supply switch to OFF (O), disconnect the power cord from the power
source, and disconnect the gas supply.
2. Remove the plasma power supply cover and the component barrier. Refer to page 49.
3. Remove the end panel bracket. Refer to page 53.
4. Loosen the rear panel. Refer to page 57.
5. Remove the 2 screws that attach the PFC inductor wires to the power PCB.
Figure 21 – Powermax65/85 SYNC PFC inductor wires
6. Remove the 2 mounting screws from the PFC inductor.
7. Remove the PFC inductor.
CSA models CE/CCC models
RED
J32
RED
J21
ORG
J20
J12
B
R
WORK
LEAD
BLK
BLK
J13
J16J17J18J19
J26
J29
TP12
J28
TP10
TP11
W
R
B
J4 J2 J1J3
RED
J33
RED
J21
ORG
J20
J12
B
R
J13
J2
J1
J19
TP13
TP11
TP12
W
R
B
J6 J5 J4 J3
WORK
LEAD
J27
J29
J18
J23
J24
J30
