Hypertherm Powermax65 SYNC User Manual

Service Parts
2
Powermax65/85 SYNC Service Parts and Procedures 810440 31
For replacement procedures, refer to the following:
 Replace the pilot arc IGBT on page 110
 Replace the inverter IGBT and the thermal sensor on page 112
 Replace the PFC IGBT on page 114
IGBT tester
You can purchase the IGBT tester separately for troubleshooting.
4 528046 Kit: Powermax85 SYNC CE inverter IGBT
209445 Pilot arc IGBT
223738 PFC to inverter cable (2)
075569 Screw: M6 X 14-12.5, pan head (3)
075851 Screw: M6 X 18.5±0.5-12.5, pan head (4)
128836 Thermal grease, 0.125 ounce
5 428990 Kit: Thermal sensor (switch)
209569 Transducer
075524 Screw: M5 X 16, pan head
075851 Screw: M6 X 18.5±0.5-12.5, pan head
6 528041 Kit: Powermax65 SYNC CSA PFC IGBT
109932 PFC IGBT
223738 PFC to inverter cable (2)
075567 Screw: M6 X 16-12.5, pan head (4)
075569 Screw: M6 X 14-12.5, pan head (3)
128836 Thermal grease, 0.125 ounce
6 528047 Kit: Powermax85 SYNC CSA PFC IGBT
1098 02 P FC IG BT
223738 PFC to inverter cable (2)
075567 Screw: M6 X 16-12.5, pan head (4)
075569 Screw: M6 X 14-12.5, pan head (3)
128836 Thermal grease, 0.125 ounce
Item
Part
number
Description and kit contents
Part number Description
128883 IGBT tester
