Hypertherm Powermax65 SYNC User Manual

Service Parts
2
Powermax65/85 SYNC Service Parts and Procedures 810440 41
Parts necessary for safety
Genuine Hypertherm parts are factory-recommended parts for your Hypertherm system. Any
damage caused by the use of parts that are not from Hypertherm may not be covered by the
Hypertherm warranty. Parts that are necessary for safety are parts that must be replaced with only
genuine Hypertherm parts to maintain the warranty and system certifications.
Part number Description Page
228680 Kit: Strain relief for Powermax65/85 SYNC power cords (all models) page 18
228691 Kit: Powermax65/85 SYNC power cord with strain relief, CSA models, 3 m
(10 foot)
page 18
528015 Kit: Powermax65 SYNC power cord with strain relief, CE/CCC models, 3 m
(10 foot)
page 18
528016 Kit: Powermax85 SYNC power cord with strain relief, CE/CCC models, 3 m
(10 foot)
page 18
228644 Kit: Powermax65 SYNC power switch CSA page 20
228655 Kit: Powermax85 SYNC power switch CSA page 20
228671 Kit: Powermax65/85 SYNC power switch CE/CCC page 20
428991 Kit: Powermax65/85 SYNC Fan assembly page 23
528029 Kit: Powermax65 SYNC power PCB CSA page 26
528030 Kit: Powermax65 SYNC power PCB CE/CCC page 26
528031 Kit: Powermax85 SYNC power PCB CSA page 26
528032 Kit: Powermax85 SYNC power PCB CE/CCC page 26
528028 Kit: DSP PCB page 27
228683 Kit: Powermax65 SYNC bulk capacitor CSA page 27
228684 Kit: Powermax65 SYNC bulk capacitor CE / CCC page 27
228681 Kit: Powermax85 SYNC bulk capacitor CSA page 27
228682 Kit: Powermax85 SYNC bulk capacitor CE / CCC page 27
228661 Kit: Powermax65 SYNC PFC inductor CSA page 33
228670 Kit: Powermax65 SYNC PFC inductor CE / CCC page 33
228668 Kit: Powermax85 SYNC PFC inductor CSA page 33
228664 Kit: Powermax85 SYNC PFC inductor CE / CCC page 33
228663 Kit: Powermax65 SYNC transformer CSA page 33
228669 Kit: Powermax65 SYNC transformer CE / CCC page 33
228667 Kit: Powermax85 SYNC transformer CSA page 33
228654 Kit: Powermax85 SYNC transformer CE / CCC page 34
528036 Kit: Powermax65 SYNC output inductor page 34
528037 Kit: Powermax85 SYNC output inductor page 34
