Service Procedures for the Cover, Panels, and Connectors
3
56 810440 Service Parts and Procedures Powermax65/85 SYNC
Attach the front panel
1. Put the fan side of the plasma power supply on a clean, dry, and flat surface.
2. Push the front panel onto the bottom of the plasma power supply.
3. Install the screws that attach the front panel to the bottom of the
plasma power supply. Tighten the screws to 2.3 Nm (20 lbfin).
4. Put the plasma power supply upright position.
5. Install the end panel bracket. Refer to page 54.
