Service Parts
2
34 810440 Service Parts and Procedures Powermax65/85 SYNC
For replacement procedures, refer to the following:
 Replace the PFC inductor on page 134
 Replace the transformer on page 130
 Replace the output inductor on page 127
2 228654 Kit: Powermax85 SYNC transformer CE / CCC
014342 Transformer
075697 Screw: M5 X 0.8 X 10-10, pan head (2)
3 528036 Kit: Powermax65 SYNC output inductor
014439 Output inductor
075697 Screw: M5 X 0.8 X 10-10, pan head (2)
3 528037 Kit: Powermax85 SYNC output inductor
014440 Output inductor
075697 Screw: M5 X 0.8 X 10-10, pan head (2)
Item
Part
number
Description and kit contents
