IAI EC-RR6*AH series User Manual

Part Names
Intro-17
Radial cylinder type
High rigidity radial cylinder type (EC-RR□□AH), High rigidity radial cylinder type (EC-RR□□H)
Opposite side Motor side
Rod tip adapto
r
Rod
Frame cove
r
End cove
r
Front bracket
Front cove
r
Base
Track housing cove
r
Motor cove
r
Teaching port
Status LED
Power / I/O
connector
Right side
Left side
Right side
Left side
Opposite side Motor side
Rod tip adaptor
Rod
Frame cover
End cover
Teaching port
Status LED
Power I/O connector
Motor cover
Track housing cover
Base
Front cover Front bracket
Motor cover base
