Part 1 Installation
(2) Assignment example of output function selection
Given below is an example of assigning output function selection 300 (error output) whose function has
been set by I/O parameter No. 46, “Output function selection 300,” to a different output port.
Use I/O parameter No. 46, “Output function selection 300” to set the function of output function selection
300 (error output). For details, refer to Appendix, “List of Parameters.”
Set the output port number for output function selection 300 (error output) using I/O parameter No. 299,
“Port number assigned to output function selection 300.”
If you set “316”, for example, the function of output function selection 300 (error output) is assigned to
“Output port No. 316.”
Accordingly, the signal for output function selection 300 (error output) is output to “Output port No. 316.”
Note, however, that setting “0 (default value: standard factory setting)” in I/O parameter No. 299, “Port
number assigned to output function selection 300” is invalid, in which case the function of output function
selection 300 (error output) will be assigned to “Output port No. 300.”
After the assignment change, “Output port No. 300” becomes a general-purpose input port.
Note: Although output port numbers can be set individually as desired, setting duplicate port numbers
will generate Error No. 685, “I/O function selection port number error.”
(3) Assignment example of output function selection (area 2)
Output function selection 300 (area 2) (error output) whose function has been set by I/O parameter No.
331, “Output function selection 300 (area 2)” can be assigned to an output port that has been set by “Port
number assigned to output function selection 300 (area 2),” to output a signal. An example is given below.
Use I/O parameter No. 331, “Output function selection 300 (area 2)” to set the function of output function
selection 300 (area 2) (error output). For details, refer to Appendix, “List of Parameters.”
Set the (area 2) output port number for output function selection 300 (area 2) (error output) using I/O
parameter No. 315, “Port number assigned to output function selection 300 (area 2).”
If you set “316”, for example, the function of output function selection 300 (area 2) (error output) is
assigned to “Output port No. 316.”
Accordingly, the signal for output function selection 300 (area 2) (error output) is output to “Output port No.
316.”
Note, however, that setting “0 (default value: standard factory setting)” in I/O parameter No. 315, “Port
number assigned to output function selection 300 (area 2)” is invalid, in which case no signal will be output.
Note: Although output port numbers can be set individually as desired, setting duplicate port numbers
will generate Error No. 685, “I/O function selection port number error.”
