IDEC OpenNet series User Manual

6: ALLOCATION NUMBERS
OPENNET CONTROLLER USER’S MANUAL 6-7
Special Internal Relays (Read Only)
M8065 RS232C Port 1 Modem Mode (Answer): Initialization String Completion Maintained Cleared
M8066 RS232C Port 1 Modem Mode (Answer): ATZ Completion Maintained Cleared
M8067 RS232C Port 1 Modem Mode Operational State Maintained Cleared
M8070 RS232C Port 1 Modem Mode (Originate): Initialization String Failure Maintained Cleared
M8071 RS232C Port 1 Modem Mode (Originate): ATZ Failure Maintained Cleared
M8072 RS232C Port 1 Modem Mode (Originate): Dialing Failure Maintained Cleared
M8073 RS232C Port 1 Modem Mode (Disconnect): Disconnect Line Failure Maintained Cleared
M8074 RS232C Port 1 Modem Mode (General Command): AT Command Failure Maintained Cleared
M8075 RS232C Port 1 Modem Mode (Answer): Initialization String Failure Maintained Cleared
M8076 RS232C Port 1 Modem Mode (Answer): ATZ Failure Maintained Cleared
M8077 RS232C Port 1 Modem Mode Line Connection Status Maintained Cleared
M8080 RS232C Port 2 Modem Mode (Originate): Initialization String Start Maintained Maintained
M8081 RS232C Port 2 Modem Mode (Originate): ATZ Start Maintained Maintained
M8082 RS232C Port 2 Modem Mode (Originate): Dialing Start Maintained Maintained
M8083 RS232C Port 2 Modem Mode (Disconnect): Disconnect Line Start Maintained Maintained
M8084 RS232C Port 2 Modem Mode (General Command): AT Command Start Maintained Maintained
M8085 RS232C Port 2 Modem Mode (Answer): Initialization String Start Maintained Maintained
M8086 RS232C Port 2 Modem Mode (Answer): ATZ Start Maintained Maintained
M8087 RS232C Port 2 Modem Mode AT Command Execution Maintained Cleared
M8090 RS232C Port 2 Modem Mode (Originate): Initialization String Completion Maintained Cleared
M8091 RS232C Port 2 Modem Mode (Originate): ATZ Completion Maintained Cleared
M8092 RS232C Port 2 Modem Mode (Originate): Dialing Completion Maintained Cleared
M8093 RS232C Port 2 Modem Mode (Disconnect): Disconnect Line Completion Maintained Cleared
M8094 RS232C Port 2 Modem Mode (General Command): AT Command Completion Maintained Cleared
M8095 RS232C Port 2 Modem Mode (Answer): Initialization String Completion Maintained Cleared
M8096 RS232C Port 2 Modem Mode (Answer): ATZ Completion Maintained Cleared
M8097 RS232C Port 2 Modem Mode Operational State Maintained Cleared
M8100 RS232C Port 2 Modem Mode (Originate): Initialization String Failure Maintained Cleared
M8101 RS232C Port 2 Modem Mode (Originate): ATZ Failure Maintained Cleared
M8102 RS232C Port 2 Modem Mode (Originate): Dialing Failure Maintained Cleared
M8103 RS232C Port 2 Modem Mode (Disconnect): Disconnect Line Failure Maintained Cleared
M8104 RS232C Port 2 Modem Mode (General Command): AT Command Failure Maintained Cleared
M8105 RS232C Port 2 Modem Mode (Answer): Initialization String Failure Maintained Cleared
M8106 RS232C Port 2 Modem Mode (Answer): ATZ Failure Maintained Cleared
M8107 RS232C Port 2 Modem Mode Line Connection Status Maintained Cleared
M8110-M8117 — Reserved ———
Allocation
Number
Description CPU Stopped Power OFF
M8120 Initialize Pulse Cleared Cleared
M8121 1-sec Clock Operating Cleared
M8122 100-msec Clock Operating Cleared
M8123 10-msec Clock Operating Cleared
M8124 Timer/Counter Preset Value Changed Maintained Maintained
Allocation
Number
Description CPU Stopped Power OFF
