OPENNET CONTROLLER USER’S MANUAL A-1
APPENDIX
Execution Times for Instructions
Execution times for main instructions of the OpenNet Controller are listed below:
Instruction
Operand and
Condition
Maximum Execution Time (µsec)
w/o Data Type Data Type: W or I Data Type: D or L
LOD, LODN 0.65
OUT, OUTN 1.15
SET, RST 1
AND, ANDN, OR, ORN 0.5
AND LOD, OR LOD 0.3
BPS 3
BRD 0.5
BPP 3
TML, TIM, TMH, TMS 43
CNT, CDP, CUD 42
CC=, CC≥, TC=, TC≥,
DC=, DC≥
22
SFR, SFRN
(N bits)
Reset input ON 190 + 1.1N
Pulse input ON 252 + 2.8N
Others 113
SOTU, SOTD 50
JMP, JEND, MCS, MCR 3
END See the next page.
MOV, MOVN
M → M 170 240
D → D7074
CMP=, <>, <, >, <=, >=
M ↔ M → M 210 260
D ↔ D → M 115 125
ADD
M + M → D 172 232
D + D → D 98 110
SUB
M – M → D 172 232
D – D → D 98 110
MUL
M × M → D 172 238
D × D → D 98 140
DIV
M ÷ M → D 205 280
D ÷ D → D 136 192
