6: ALLOCATION NUMBERS
6-4 OPENNET CONTROLLER USER’S MANUAL
Operand Allocation Numbers for Functional Modules
Operand Allocation Numbers for Master Module
Functional Module
Allocation Numbers
Data Area
Status Area
(Read Only)
Reserved Area
(Access Prohibited)
Functional Module 1 L0100-L0107 L0110-L0117 L0120-L0127
Functional Module 2 L0200-L0207 L0210-L0217 L0220-L0227
Functional Module 3 L0300-L0307 L0310-L0317 L0320-L0327
Functional Module 4 L0400-L0407 L0410-L0417 L0420-L0427
Functional Module 5 L0500-L0507 L0510-L0517 L0520-L0527
Functional Module 6 L0600-L0607 L0610-L0617 L0620-L0627
Functional Module 7 L0700-L0707 L0710-L0717 L0720-L0727
Node
Allocation Numbers
Input Data Output Data
Node 0 L1000-L1003 L1004-L1007
Node 1 L1010-L1013 L1014-L1017
Node 2 L1020-L1023 L1024-L1027
Node 3 L1030-L1033 L1034-L1037
Node 4 L1040-L1043 L1044-L1047
Node 5 L1050-L1053 L1054-L1057
Node 6 L1060-L1063 L1064-L1067
Node 7 L1070-L1073 L1074-L1077
Node 8 L1080-L1083 L1084-L1087
Node 9 L1090-L1093 L1094-L1097
Node 10 L1100-L1103 L1104-L1107
Node 11 L1110-L1113 L1114-L1117
Node 12 L1120-L1123 L1124-L1127
Node 13 L1130-L1133 L1134-L1137
Node 14 L1140-L1143 L1144-L1147
Node 15 L1150-L1153 L1154-L1157
Node 16 L1160-L1163 L1164-L1167
Node 17 L1170-L1173 L1174-L1177
Node 18 L1180-L1183 L1184-L1187
Node 19 L1190-L1193 L1194-L1197
Node 20 L1200-L1203 L1204-L1207
Node 21 L1210-L1213 L1214-L1217
Node 22 L1220-L1223 L1224-L1227
Node 23 L1230-L1233 L1234-L1237
Node 24 L1240-L1243 L1244-L1247
Node 25 L1250-L1253 L1254-L1257
Node 26 L1260-L1263 L1264-L1267
Node 27 L1270-L1273 L1274-L1277
Node 28 L1280-L1283 L1284-L1287
Node 29 L1290-L1293 L1294-L1297
Node 30 L1300-L1303 L1304-L1307
Node 31 L1310-L1313 L1314-L1317
