6: ALLOCATION NUMBERS
OPENNET CONTROLLER USER’S MANUAL 6-3
For details about allocation numbers of link registers, see page 6-4.
For details about allocation numbers used for data link communication, see page 6-5.
Internal Relay (M)
M1000-M1007 M1010-M1017 M1020-M1027 M1030-M1037
M1040-M1047 M1050-M1057 M1060-M1067 M1070-M1077
M1080-M1087 M1090-M1097 M1100-M1107 M1110-M1117
M1120-M1127 M1130-M1137 M1140-M1147 M1150-M1157
M1160-M1167 M1170-M1177 M1180-M1187 M1190-M1197
M1200-M1207 M1210-M1217 M1220-M1227 M1230-M1237
M1240-M1247 M1250-M1257 M1260-M1267 M1270-M1277
M1280-M1287 M1290-M1297 M1300-M1307 M1310-M1317
M1320-M1327 M1330-M1337 M1340-M1347 M1350-M1357
M1360-M1367 M1370-M1377 M1380-M1387 M1390-M1397
M1400-M1407 M1410-M1417 M1420-M1427 M1430-M1437
M1440-M1447 M1450-M1457 M1460-M1467 M1470-M1477
M1480-M1487 M1490-M1497 M1500-M1507 M1510-M1517
M1520-M1527 M1530-M1537 M1540-M1547 M1550-M1557
M1560-M1567 M1570-M1577 M1580-M1587 M1590-M1597
M1600-M1607 M1610-M1617 M1620-M1627 M1630-M1637
M1640-M1647 M1650-M1657 M1660-M1667 M1670-M1677
M1680-M1687 M1690-M1697 M1700-M1707 M1710-M1717
M1720-M1727 M1730-M1737 M1740-M1747 M1750-M1757
M1760-M1767 M1770-M1777 M1780-M1787 M1790-M1797
M1800-M1807 M1810-M1817 M1820-M1827 M1830-M1837
M1840-M1847 M1850-M1857 M1860-M1867 M1870-M1877
M1880-M1887 M1890-M1897 M1900-M1907 M1910-M1917
M1920-M1927 M1930-M1937 M1940-M1947 M1950-M1957
M1960-M1967 M1970-M1977 M1980-M1987 M1990-M1997
M2000-M2007 M2010-M2017 M2020-M2027 M2030-M2037
M2040-M2047 M2050-M2057 M2060-M2067 M2070-M2077
M2080-M2087 M2090-M2097 M2100-M2107 M2110-M2117
M2120-M2127 M2130-M2137 M2140-M2147 M2150-M2157
M2160-M2167 M2170-M2177 M2180-M2187 M2190-M2197
M2200-M2207 M2210-M2217 M2220-M2227 M2230-M2237
M2240-M2247 M2250-M2257 M2260-M2267 M2270-M2277
M2280-M2287 M2290-M2297 M2300-M2307 M2310-M2317
M2320-M2327 M2330-M2337 M2340-M2347 M2350-M2357
M2360-M2367 M2370-M2377 M2380-M2387 M2390-M2397
M2400-M2407 M2410-M2417 M2420-M2427 M2430-M2437
M2440-M2447 M2450-M2457 M2460-M2467 M2470-M2477
M2480-M2487 M2490-M2497 M2500-M2507 M2510-M2517
M2520-M2527 M2530-M2537 M2540-M2547 M2550-M2557
2048
Special Internal Relay (M)
M8120-M8237 for read only
M8000-M8007 M8010-M8017 M8020-M8027 M8030-M8037
M8040-M8047 M8050-M8057 M8060-M8067 M8070-M8077
M8080-M8087 M8090-M8097 M8100-M8107 M8110-M8117
192
M8120-M8127 M8130-M8137 M8140-M8147 M8150-M8157
M8160-M8167 M8170-M8177 M8180-M8187 M8190-M8197
M8200-M8207 M8210-M8217 M8220-M8227 M8230-M8237
Shift Register (R) R0000-R0255 256
Timer (T) T0000-T0255 256
Counter (C) C0000-C0255 256
Data Register (D) D0000-D7999 8000
Special Data Register (D) D8000-D8999 1000
Link Register (L)
L0100-L0127 L0200-L0227 L0300-L0327 L0400-L0427
L0500-L0527 L0600-L0627 L0700-L0727
Slave: 168
L1000-L1317 Master: 256
Operand Allocation Numbers Total Points
