APPENDIX
OPENNET CONTROLLER USER’S MANUAL A-3
Type List
CPU Modules
Note: Every CPU module is supplied with a pair of end plates.
Input Modules
Output Modules
Expansion Power Supply Module
Note: The expansion power supply module is supplied with a cable/connector (1 meter long) and 3 contacts for expanding
cables.
HSC Output Memory Card Connector Type No.
Sink Output Type
Without FC3A-CP2K
With FC3A-CP2KM
Source Output Type
Without FC3A-CP2S
With FC3A-CP2SM
Input Type Input Points Terminal/Connector Type No.
24V DC Sink/Source
16 points
Screw Terminal FC3A-N16B1
Nylon Connector (10P × 2) FC3A-N16B3
32 points
Nylon Connector (18P × 2) FC3A-N32B4
Fujitsu Connector FC3A-N32B5
100-120V AC Input 8 points Screw Terminal FC3A-N08A11
Analog Input
12-bit (resolution 1/4000) 6 channels
4-20mA, 0-5V, 0-10V, ±5V, ±10V input
Screw Terminal FC3A-AD1261
Output Type Output Points Terminal/Connector Type No.
Relay Output
(240V AC/24V DC, 2A)
16 points
Screw Terminal FC3A-R161
Nylon Connector (5P × 4) FC3A-R162
Transistor Sink Output
24V DC, 0.5A/point
2.0A/common
16 points
Screw Terminal FC3A-T16K1
Nylon Connector (10P × 2) FC3A-T16K3
Transistor Protect Source Output
24V DC, 0.5A/point
2.0A/common
16 points Screw Terminal FC3A-T16P1
Transistor Sink Output
24V DC, 0.1A/point
2.0A/common
32 points
Nylon Connector (18P × 2) FC3A-T32K4
Fujitsu Connector FC3A-T32K5
Analog Output
12-bit (resolution 1/4000) 2 channels
4-20mA, 0-5V, 0-10V, ±5V, ±10V output
Screw Terminal FC3A-DA1221
Description Connector Type No.
Input Power Voltage 24V DC Nylon Connector (5P × 1) FC3A-EA1
