6: ALLOCATION NUMBERS
OPENNET CONTROLLER USER’S MANUAL 6-5
Operand Allocation Numbers for Data Link Master Station
Note: When any slave stations are not connected, master station data registers which are assigned to the vacant slave sta-
tions can be used as ordinary data registers.
Operand Allocation Numbers for Data Link Slave Station
Note: Slave station data registers D7020 through D7619 and D8401 through D8430 can be used as ordinary data regis-
ters.
Slave Station Number
Allocation Number
Transmit Data
to Slave Station
Receive Data
from Slave Station
Data Link
Communication Error
Slave Station 1 D7000-D7009 D7010-D7019 D8400
Slave Station 2 D7020-D7029 D7030-D7039 D8401
Slave Station 3 D7040-D7049 D7050-D7059 D8402
Slave Station 4 D7060-D7069 D7070-D7079 D8403
Slave Station 5 D7080-D7089 D7090-D7099 D8404
Slave Station 6 D7100-D7109 D7110-D7119 D8405
Slave Station 7 D7120-D7129 D7130-D7139 D8406
Slave Station 8 D7140-D7149 D7150-D7159 D8407
Slave Station 9 D7160-D7169 D7170-D7179 D8408
Slave Station 10 D7180-D7189 D7190-D7199 D8409
Slave Station 11 D7200-D7209 D7210-D7219 D8410
Slave Station 12 D7220-D7229 D7230-D7239 D8411
Slave Station 13 D7240-D7249 D7250-D7259 D8412
Slave Station 14 D7260-D7269 D7270-D7279 D8413
Slave Station 15 D7280-D7289 D7290-D7299 D8414
Slave Station 16 D7300-D7309 D7310-D7319 D8415
Slave Station 17 D7320-D7329 D7330-D7339 D8416
Slave Station 18 D7340-D7349 D7350-D7359 D8417
Slave Station 19 D7360-D7369 D7370-D7379 D8418
Slave Station 20 D7380-D7389 D7390-D7399 D8419
Slave Station 21 D7400-D7409 D7410-D7419 D8420
Slave Station 22 D7420-D7429 D7430-D7439 D8421
Slave Station 23 D7440-D7449 D7450-D7459 D8422
Slave Station 24 D7460-D7469 D7470-D7479 D8423
Slave Station 25 D7480-D7489 D7490-D7499 D8424
Slave Station 26 D7500-D7509 D7510-D7519 D8425
Slave Station 27 D7520-D7529 D7530-D7539 D8426
Slave Station 28 D7540-D7549 D7550-D7559 D8427
Slave Station 29 D7560-D7569 D7570-D7579 D8428
Slave Station 30 D7580-D7589 D7590-D7599 D8429
Slave Station 31 D7600-D7609 D7610-D7619 D8430
Data
Allocation Number
Transmit Data
to Master Station
Receive Data
from Master Station
Data Link
Communication Error
Slave Station Data D7000-D7009 D7010-D7019 D8400
